Quad Pod mk5

Quad Pod

ProLink

Prolink

K45 Lite

K45-Lite

K21

K21

ReelSpeedyLight-50m

Reel Speedy Light

Rite-Power 7000 1750

Rite-Power Battery Generator

K65 QUAD POD

Speedy Product Code 35/0562

  • USED FOR:
  • Storage / Welfare Yard
  • Access Point
Quad Pod mk5

Key Features & Benefits

  • High Power, LED mobile area lighting tower providing superb illumination over a large area from low power requirement
  • Approximately 70% lower light pollution than typical lighting tower designs
  • Easy & safe to store, transport and set up with 6.5M max height
  • Compact to store, mobile over any terrain
  • Light heads can be positioned for 180˚ to 360˚ illumination with average 20 lux illumination over 6868m2 area.
  • Powered by diesel generators, mains power or RITE-POWER portable battery powered generators
K50 - Rail

QuadPod Photo Gallery

K45-LITE

Speedy Product Code 35/0556

  • USED FOR:
  • Open Track
  • Storage / Welfare Yard
  • Access Point
K45 Lite

Key Features & Benefits

  • High power, Multi-Functional 360o Area lighting system
  • 85,000 lumen output
  • Directional or 360o area lighting
  • Easy to transport and setup,
  • Fast, simple, safe deployment system
  • Light to carry along tracks
  • 3.1-4.1m height optional tripods from small ground footprint
  • Fitted with standard DIN tripod mounting for use with all industry standard tripods with DIN spigot
  • Fully dimmable for optimum control of light output and run-time when using the RITE-POWER battery powered generators

Typical Installation

K45-Lite From Above

Recommended distance up to 60M apart (20 lux average area @ 100% power)

Power Options for the K45-LITE
1 x RITE-POWER 1750 Battery Generator will power 1 x K45-LITE for 2.5 hours at full power
1 x RITE-POWER 1750×2 Battery Generator will power 1 x K45-LITE for 5 hours at full power or 16 hours @ 30% power

Setup Options

360 Degree Area Lighting

Directional Area Lighting

K45-LITE Photo Gallery

Product Used With

K21 LED BEAM CONTROL TWIN HEAD

Speedy Product Code 35/0501 | Twin Head Adaptor 35/0502 | Mag Braket 35/0503 | Tripod 22/0142

  • USED FOR:
  • Open Track
  • Tunnels
K21

Key Features & Benefits

  • Advanced beam control optics for optimised light spread
  • High levels of uniformity and no dark spots
  • Minimal light spill / pollution
  • Beam control prevents light being wasted and spilt where not wanted
  • Maximum efficiency achieved
  • Only 220W of power
  • Compact low weight
  • Twin element hybrid optics
  • Configurable to single or twin mounting
  • Magnet mounting / Pole / Fence mounting options
K21 Grantham Switch Peascliffe

Typical Installation

K21 Gantry Dual
K21 fitted to gantry or tripod, dual lights

84 lux average. 50 lux minimum. 50m spacing

K21 Gantry Single
K21 fitted to gantry, single light

40 lux average. 25 lux minimum. 50m spacing

K21 Staggered Gantry
K21 fitted to gantry or tripod, staggered down track dual lights

85 lux average. 14 lux minimum. 100m spacing alternate

Power Options for the K21
1 x RITE-POWER 1750×2 Battery generator will power 1 x K21 light for 30 hours
1 x RITE-POWER 1750×2 Battery generator will power 2 x K21 lights for 15 hours
1 x RITE-POWER 3850 Battery generator will power 2 x K21 lights for up to 16 hours
1 x RITE-POWER 7770 Battery generator will power 4 x K21 lights for up to 16 hours

K21 Photo Gallery

Product Used With

Reel Speedy Light

Speedy Product Code 35/0602

  • USED FOR:
  • Tunnels
  • Access Point
ReelSpeedyLight-50m

Key Features & Benefits

  • Quick lighting solution for tunnels and access areas
  • Fast, easy installation
  • Compact cable reel
  • 15M – 50M options available
  • IP65 waterproof
  • 6400K daylight colour

Reel Speedy Light Photo Gallery

RITE-POWER Industrial Portable Battery Powered Generators

Speedy Product Code: RP1750 – 35/0543 | RP3850 – 35/0561 | RP7000 – 35/0598

  • USED FOR:
  • Open Track
  • Tunnels
  • Storage / Welfare Yard
  • Access Point
  • Trolley Mounted
Rite-Power 7000 1750

Key Features & Benefits

  • Ultra flexible, reliable portable power supply for any remote power location
  • Powers Ritelite lighting products and other compatible equipment including tools
  • Silent, fume free, safe operation for indoor and outdoor use.
  • No fuel requirements, rechargeable lithium batteries
  • No maintenance requirements
  • Highly portable and able to easily be removed from site avoiding security issues
  • Long duration solution for weekend work
  • Rugged, strong and designed for industrial environments
SLK1770BP
Optional pass through power transfer system

RITE-POWER Photo Gallery

Product Used With

1 Step 1
Rail Lighting Solutions

Lighting solutions for your Lighting scenario

prolink

PROLINK

Quantity
[field69]
Average Lux
[field72]
prolink

K21

Quantity
[field70]
Average Lux
[field73]
prolink

K45 LITE

Quantity
[field71]
Average Lux
[field74]

Lighting solutions for your Lighting scenario

prolink

K21

Quantity
[field70]
Average Lux
[field73]
prolink

K45 LITE

Quantity
[field71]
Average Lux
[field74]

Power your lighting scenario with the

Battery Generator Duration per solution (Hours per model)

RITE-POWER Portable Battery Solutions RP-1750 RP-1750x2
PROLINK x[field69] [(1750*0.9)/(field69*15)] hours [(3500*0.9)/(field69*15)] hours
K21 x[field70] [(1750*0.9)/(field70*230)] hours [(3500*0.9)/(field70*230)] hours
K45 LITE x[field71]  [(1750*0.9)/(field71*650)] hours [(3500*0.9)/(field71*650)] hours
RITE-POWER Portable Battery Solutions RP-3850 RP-7000
PROLINK x[field69] [(3850*0.9)/(field69*15)] hours [(7700*0.9)/(field69*15)] hours
K21 x[field70] [(3850*0.9)/(field70*230)] hours [(7700*0.9)/(field70*230)] hours
K45 LITE x[field71]  [(3850*0.9)/(field71*650)] hours [(7700*0.9)/(field71*650)] hours
Linkable for extra capacity

ProlinkValue = [field69]

ProlinkValueLux = [field72]

K21Value = [field70]

K21ValueLux = [field73]

K45Value = [field71]

K45ValueLux = [field74]

Please note that the above figures do not cover for any losses through distance of cables and / or connections on site.

Please see scenario pages above for typical light and RITE-POWER generator kit set ups.

Find out how much CO2 you can save

Submit Fields = [field97]

Submit your enquiry for a full quotation
GDPR confirm

Thanks for visiting our website. If you would like to discuss your lighting requirements further please contact the Speedy Rail Control Centre

T: 01942 272982
