Ultra Lightweight, High Power, Multi Function 360 degree Area Lighting Systems
LIGHT UP YOUR WORK SITE AND NOT THE SKY!! THE K45-LITE & K45-ULTRA-LITE AREA LIGHTING SYSTEMS PUT MORE LIGHT WHERE YOU NEED IT – FIND OUT WHY!
High power LED
23kg total weight with 4M Tripod. Highly portable, easy to carry & transport
Rapid, Safe Deployment up to 4.7M Height
2 Light head options to meet all temporary area lighting applications.
Both fully dimmable for optimum control of light output and run time.
Directional or 360 degree flexible deployment provides unrivalled and optimised illumination of any work site.
Designed with Ritelite Beam Control - for maximum usable light
WHAT IS UNIQUE ABOUT THE K45-LITE?
Best in class power efficiency - Highly efficient LED Light heads and driver deliver a powerful 85,000 lumens at only 650W power consumption.
Ultra Lightweight - 23kg total system weight (with 4M tripod) split into 2 easy to carry modules. Can be carried safely by one person or split between two people when carrying to remote locations or over difficult terrain
Safety Stability System - specially engineered, highly robust, lightweight tripods with additional flexible ballast bag system allows on site materials to be used to optimise stability without adding unnecessary weight when carrying to site.
3.1-4.7M height from small ground footprint. Flexible & robust to cope with any remote lighting application. Fitted with standard DIN Tripod mounting for use with all industry standard tripods with DIN spigot.
Maximum usable light in any application - Industry leading triple light head design + Ritelite Light Management System provides unrivalled and optimised illumination of any work site from 180° directional to 360° area floodlighting
Easy to transport and compact to store. Multiple units can fit into the back of a car or van.
WHAT IS UNIQUE ABOUT THE K45-LITE?
Best in class power efficiency - Highly efficient LED Light heads and driver deliver a powerful 85,000 lumens at only 650W power consumption.
Ultra Lightweight - 23kg total system weight split into 3 easy to carry modules. Can be carried safely by one person or split between two people when carrying to remote locations or over difficult terrain
Safety Stability System - specially engineered, highly robust, lightweight tripods with additional flexible ballast bag system allows on site materials to be used to optimise stability without adding unnecessary weight when carrying to site.
3.1-4.7M height from small ground footprint. Flexible & robust to cope with any remote lighting application. Fitted with standard DIN Tripod mounting for use with all industry standard tripods with DIN spigot.
Maximum usable light in any application - Industry leading triple light head design + Ritelite Light Management System provides unrivalled and optimised illumination of any work site from 180° directional to 360° area floodlighting
Easy to transport and compact to store. Multiple units can fit into the back of a car or van.
K45-ULTRA-LITE
Triple light head design offering 43,500 lumens from only 320W power requirement
Compatible with a number of tripod solutions for maximum compatibility and use in different applications
Ultra Lightweight Lighthead weighting only 9kg. Can be carried safely by one person
Triple head design can be set up between 180 and 360 degrees depending on application giving users maximum flexibility
K45-ULTRA-LITE
Triple light head design offering 43,500 lumens from only 320W power requirement
Ultra Lightweight Lighthead weighting only 9kg. Can be carried safetly by one person
Compatible with a number of tripod solutions for maximum compatibility and use in different applications
K45 Ultra-Lite 180 degreesTriple head design can be set up between 180 and 360 degrees depending on application giving users maximum flexibility
FLEXIBLE LIGHTING FOR ALL APPLICATIONS
360 Degree Area Lighting
For applications where multi-directional lighting is required
6 x 100W Light heads on K45-LITE Average 20 lux over 3552 m2
based on a deployed height of 4.1m
Directional Area Lighting
For Industrial Lighting
6 x 100W Light heads on K45-LITE Average 20 lux over 2028 m2
based on a deployed height of 4.1m
Ritelite Beam Control for the K45-LITE
TECHNICAL SPECIFICATIONS OF THE K45-LITE AREA FLOODLIGHT
Best in class power efficiency
The K45-LITE’s highly efficient LED light heads and driver system delivers a powerful 85,000 lumens at only 650W power consumption.
Fast, simple, safe deployment systems
Rapid one person deployment, minimal physical effort required
3.1-4.7m height from small ground footprint
Provides excellent illumination of large areas requiring temporary lighting.
Easy to transport
Compact when stowed. Low weight. Multiple units can be transported in a small vehicle.
Mains, Generator and Battery powered
For use with existing power supplies. 110V or 240V options available compatible with petrol or diesel generators or RITE-POWER battery powered generators.
Individual, fully adjustable light heads
Allows light to be adjusted to suit any application including a 360º light pattern.
Mains, Generator and Battery powered
For use with existing power supplies. 110V or 240V options available compatible with petrol or diesel generators or RITE-POWER battery powered generators.
Ultra Lightweight
23kg max total system weight split into easy to carry modules. Can be carried safely by one person..
Best in class power efficiency
Highly efficient LED light heads and driver system delivers a powerful 85,000 lumens at only 820W power consumption.
Maximum usable light in any application
Industry leading triple light head design & Ritelite light management system.
Built-in light level control
To enable light levels to be adjusted to assist operator setup and reduce power consumption when lower light levels provide sufficient light for the task required. Enables optimum control of light output and run-time when using the optional mobile 110V & 230V battery powered generators.
LIGHT HEAD OPTIONS
K45-LITE with Integral LED Driver
- SLK45-LITE-S
- Light Output 85,000 Lumens
- Weight 14Kg (excluding tripod)
- Power Requirement 650W
K45-LITE & Separate LED Driver
- SLK45-LITE
- Light Output 85,000 Lumens
- Light head weight – 9.44kg
- Driver weight – 5kg
- Power Requirement 650W
K45-Ultra-LITE with Integral LED Driver
- SLK45-ULTRA-LITE
- Light Output 43,500 Lumens
- Weight 9Kg (excluding tripod)
- Power Requirement 320W
GENERAL SPECIFICATION
Height Deployed – 3.1 – 4.7m (depending on tripod)
Mast type – manual
4.2m Heavy Duty Tripod
(inc. male stud)
Dimensions:-
Closed: 1850mm (H)
Open: 4200mm max height extended x ø1900mm
Max Footprint: ø1900mm
Weight: 21kg
All Terrain Tripod
(inc. male stud)
Dimensions:-
Closed: 1320mm (H) x ø180mm (W)
Open: 4000mm max height extended x ø2060mm
Max Footprint: ø2060mm
Weight: 8.7kg
Indoor Tripod
(inc. male stud)
Dimensions:-
Closed: 1500mm x ø130mm
Open: 3055mm x ø1350mm
Max Footprint: ø1350mm
Weight: 6kg
Tripod Ballast Bags
A set of three ballast bags which can be attached to the legs of the K45-LITE tripod to increase the stability of the unit.
110V 14m Extension Lead
Extension leads are available in a variety of lengths to meet customer requirements. We offer a choice of plugs and sockets suitable for any country or voltage and also a choice of cable specifications. Please contact our sales department on 01780 758585 to discuss specific requirements.
240V 14m Extension Lead
Extension leads are available in a variety of lengths to meet customer requirements. We offer a choice of plugs and sockets suitable for any country or voltage and also a choice of cable specifications. Please contact our sales department on 01780 758585 to discuss specific requirements.
Rite-Power 1750 Portable Battery Powered Generator
A 750W industrial portable battery powered generator enabling the supply of power for tools, lighting and construction equipment. Easy to transport, manoeuvre and charge with zero emissions and silent and safe operation.
Rite-Power 1750×2 Portable Battery Powered Generator
A 750W industrial portable battery powered generator that enabling supply of power for tools, lighting and construction equipment. Easy to transport, manoeuvre and charge with zero emissions and silent and safe operation.
Rite-Power 3850 Portable Battery Powered Generator
A 2500W industrial portable power generator with a rugged, compact waterproof case with industrial input and output sockets configurable as required.
Rite-Power 5250 Portable Battery Powered Generator
The RITE-POWER 5250 model of portable battery powered generator supplies 5250WH of energy at 2500W continuous power to use with lights, tools and other construction or site equipment. Zero emissions and safe operation.
Rite-Power 7700 Portable Battery Powered Generator
The RITE-POWER 7700 portable battery powered generator supplies 2500W continuous power from a 7700 WH energy bank to power tools, lighting and construction equipment. Safe and silent operation with zero emissions.
1.6KW Industrial Generator 110V or 240V
A power source for applications including construction sites, sports fields, and events with a 110V or 240V output.
3.0KW Electric Start 100V or 240V
A power source for applications including construction sites, sports fields, and events. Available with either a 110V or 240V output.
- What is the difference between the K45-LITE and K45-ULTRA-LITE products?
The K45-ULTRA-LITE is a lower wattage, lower lumen optional light head offering 43,500 lumens from only 320W power requirement. It has an in-built driver and weights only 9kg. The K45-LITE offers double the lumen output – a high 85,000 lumens with a 650W power requirement. It can be supplied either with our without an internal driver depending on application. - Can the K45 be used with any tripod?
Both the K45-LITE and K45-ULTRA-LITE are fitted with a din adaptor enabling them to be used on any tripod with a standard connector. Ritelite offers a number of different tripods of different height and weight to meet almost any temporary lighting requirement. - What can the K45-LITE products be powered by?
The K45-LITE products can be powered by any generator or the Ritelite RITE-POWER range of battery powered generators. Check out the compatible models on the accessories tab. - How easy is the K45-LITE to transport?
The K45-LITE is very easy to transport. The whole system is under 30Kg depending on light head / tripod combination which are split into 2 or 3 easy to carry modules for ultimate flexibility when using in remote areas. - Can the K45-LITE run from a 240v supply?
The unit has a range of 100-240V so will work fine with 240V circuits. The type of connector needed must be specified when ordering.
