K41 360

A High-Performance, Multi-Functional 360º LED Lighting System, Built For Demanding Environments

Up to 92,000 Equivalent Lumens Light Output

KEY FEATURES OF THE K41 PORTABLE AREA FLOOD LIGHTING SYSTEM?

K41
K41
K41

RUGGED CONSTRUCTION FOR MAXIMUM APPLICATIONS

K41 - Construction

Polyethylene impact resistance handles

Robust aluminium case

K41 - Stackable

Stackable and compact for transport and storage

Folding suspension eye for 360° deployment

K41 Robust

Robust aluminium case

K41 Area Lighting System Models

There are 3 standard K41 models to meet every application and budget. Additional optional features are available for all models outlined below with other bespoke specifications also available.

K41-S1 K41-Model-S1

180-360° configurable light system. Simple on / off control of the light with the light level able to be set to meet requirements via an integrated digital dimmer system from 0 -100% brightness. 5m down lead fitted. 110V or 240V input available.

K41-Model-S1-Img1

Standard lead

K41-Model-S1-Img2

Dimmer on head

K41-S2 K41-Model-S2

As S1 model but with the additional functionality of a light head mounted Dusk To Dawn (D2D) switch and a link box at the power input to enable multiple lights to be linked or daisy chained together to run from one power source.

K41-Model-S2-Img1

+ Linkable pendant

K41-Model-S2-Img2

+ Dusk to Dawn sensor

K41-S3 K41-Model-S3

The S3 model has all the functionality of the S1 & S2 models plus all light function controls within the ground level pendant. It also includes a microwave occupancy sensor enabling the light to automatically turn on at a pre-set level when motion is detected.

K41-Model-S3-Img1

+ Ground level control box

K41-Model-S3-Img2

+ Microwave occupancy sensor

K41
Features K41-S1 K41-S2 K41-S3
K41 Dimmer 0-100% Dimmer ✓ ✓ ✓
Control Method In Lighthead In Lighthead Ground Level Pendant
K41 - Linkable Linkable functionality to other lights or equipment N/A ✓ ✓
Link position N/A Ground Level Ground Level
K41 Dusk-to-Dawn Dusk-to-Dawn sensor N/A ✓ ✓
Control position N/A In Lighthead Ground Level Pendant
K41 Sensing Occupancy sensing ✗ ✗ ✓
Control position Ground Level Pendant
K41 Pendant connector Detachable inline pendant connector system ✗ ✗ optional
K41 Input 110V or 240V input ✓ ✓ ✓
K41 5M cable 5M cable with 110V or 240V plug ✓ ✓ ✓
K41 Diffuser Diffuser glare reduction screen optional optional optional
Folding suspension eye for 360° deploy optional optional optional
Pendant lockout box N/A N/A optional
Find me indication light optional optional optional

FLEXIBLE LIGHTING FOR ALL APPLICATIONS

TECHNICAL SPECIFICATIONS OF THE K41 AREA FLOODLIGHT
